Avro-Lancaster Bombers

Marshall of the Royal Air Force Sir Arthur T. Harris

wartime chief of Bomber Command

During World War II, the Lancaster was the most successful bomber used by the Royal Air Force and the Royal Canadian Air Force. The Lanc had speed, ceiling, and lifting power that no other aircraft of the day could match. Weighing 36,900 pounds empty, the Lancaster was capable of taking off with an additional 33,100 pounds of fuel and bombs; in other words it could almost carry its own weight again.



The Lancaster carried 64% of the tonnage dropped by the RAF and RCAF during the war. The “Grand Slam,” a 22,000 pound special purpose bomb designed to penetrate concrete and explode below the surface to create an earthquake effect, could only be delivered by the Lancaster and the Lancaster was thus chosen for special operations such as the “Dambusters” raid and the attack which sunk the German Battleship Tirpitz.

Lancasters were built to accomplish their specific purpose and crew comfort and security was clearly a secondary consideration. Generally flying under the cover of darkness, the Lancaster had virtually no defensive armour. The front, mid-upper, and rear gun turrets were hydraulically powered and carried a total of eight .303 calibre machine guns for defence against enemy aircraft.

The crew worked in cramped conditions, particularly the air gunners who remained at their posts for the entire flight. Some had to place their flight boots into the turrets before climbing in, and then put their boots on. At night and at 20,000 feet the temperature in the turrets frequently fell to minus forty degrees and frostbite was not uncommon. Air gunners manned the rear and mid-upper gun turrets. A pilot, flight engineer, navigator, wireless operator, and bomb aimer/front gunner completed the crew of seven.

The Lanc's massive bomb bay stretched for 33 feet and, unlike other bombers, was one continuous uninterrupted space. Partly for this reason, the Lanc had the versatility to undertake raids with large, specialized weapons. However, this meant that the main wing spars became obstacles to movement within the aircraft, particularly for airmen wearing heavy clothing and flight boots.

Of the total of 7377 Lancasters built (430 of them in Canada), 3932 were lost in action. During the war Lancasters flew a total of 156 308 sorties and dropped 608,612 tons of bombs, and placed over 12,000 mines in enemy waters.

Another view of the FM212 Lancaster taken by Ronald Blaine Fluhrer in 1965 shortly after she was installed in Jackson Park, Windsor, Ontario. Forty years later, she was moved to a hangar at Windsor Airport for restoration work and given the name "Bad Penny" in memory of Windsor Pilot Bob Upcott's heroic first flight.

Some of the aircraft's finest hours were in “non-offensive” operations as the war was about end and shortly after peace finally was in place. The first of these was during “Operation Manna.” Lancaster squadrons dispatched a total of 3,156 sorties to drop 6,684 tons of food supplies to the starving Dutch in May 1945. The second saw many of the Lancaster squadrons tasked to return Allied Prisoners of War from various locations throughout Europe back to England. In a period of 24 days a total of 2900 round trips were flown and 74,000 ex-POW's were returned.

With the end of hostilities on all war fronts, the Lancaster was by no means finished in its service. The RAF continued to use the aircraft in various roles including photographic and maritime duties until October 1956. The Royal Canadian Air Force, who flew back many of the surviving Mk.X's back to Canada, continued to use the aircraft in photographic and maritime reconnaissance roles until the early 1960s. The last three RCAF Lancasters were retired at a ceremony on April 1, 1964.

General Characteristics

  • Crew: 7: pilot, flight engineer, navigator, bomb aimer/nose gunner, wireless operator, mid-upper and rear gunners

  • Length: 69 ft 4 in (21.13 m)

  • Wingspan: 102 ft 0 in (31.09 m)

  • Height: 20 ft 6 in (6.25 m)

  • Wing area: 1,297 sq ft (120.5 m2)

  • Airfoil: root: NACA 23018; tip: NACA 23012

  • Empty weight: 36,900 lb (16,738 kg)

  • Gross weight: 55,000 lb (24,948 kg)

  • Max takeoff weight: 68,000 lb (30,844 kg)

  • Powerplant: 4 × Rolls-Royce Merlin XX V-12 liquid-cooled piston engines, 1,280 hp (950 kW) each

  • Propellers: 3-bladed

Performance

  • Maximum speed: 282 mph (454 km/h, 245 kn) at 63,000 lb (28,576 kg) and 13,000 ft (3,962 m) altitude

  • Cruise speed: 200 mph (320 km/h, 170 kn)

  • Range: 2,530 mi (4,070 km, 2,200 nmi)

  • Service ceiling: 21,400 ft (6,500 m) at 63,000 lb (29,000 kg)

  • Rate of climb: 720 ft/min (3.7 m/s) at 63,000 lb (29,000 kg) and 9,200 ft (2,800 m) altitude

Armament

  • Guns: Two 0.303-inch (7.7 mm) Browning Mark II machine guns in nose turret, two 0.303-inch Browning Mark II machine guns in upper turret, and four 0.303-inch Browning Mark II machine guns in the rear turret. (Early aircraft had two Brownings in a ventral turret aimed from within the aircraft via a periscope.)

  • Bombs: Maximum normal bomb load of 14,000 lb (6,400 kg) of bombs

Avionics

  • H2S radar in later variants

  • T1154 and R1155 radios

  • Gee

  • Monica

  • various other nav-aids and countermeasures



Lancaster in Colour, WWII
Lancaster in Colour, WWII
press to zoom
Assembly Line
Assembly Line

Lancasters on Avro's Woodford assembly line at Cheshire, 1943

press to zoom
Lancaster Assembly Line
Lancaster Assembly Line

Avro's factory at Woodford, Cheshire, 1943

press to zoom
Wireless Operator
Wireless Operator

Inside G for George of No. 460 Squadron. Looking forward between wing spars. At left the wireless operator, at right the navigator

press to zoom
Flight Engineer
Flight Engineer

The flight engineer checks control panel from his seat

press to zoom
Bomb Bay
Bomb Bay

"Abnormal" industrial demolition load of 14 1,000-pound MC (medium capacity) high-explosive bombs

press to zoom
No.57 Squadron Lancaster mid-upper_gunner_in_his_turret
No.57 Squadron Lancaster mid-upper_gunner_in_his_turret

February, 1943

press to zoom
Lancaster pigeons
Lancaster pigeons

Canadian PO (A) S Jess, wireless operator of an Avro Lancaster bomber operating from Waddington, Lincolnshire carrying two pigeon boxes. Homing pigeons served as a means of communications in the event of a crash, ditching or radio failure.

press to zoom
Lancaster 44 Squadron
Lancaster 44 Squadron

Three 44 Squadron Avro Lancaster B.Is in 1942
